Eantenna and 1217306
- Write a review
€242.50
{
{
EANTENNA builds rows antennas which consist of different individual diopoli on a single Balun. This means that only one coaxial cable is needed for placing on the net, but each band has its own dipole. {
The lowest bands 40m and 80m have a coil to reduce the overall length of the antennas. {
{capacity: 1500 Watt Pep. {
{
| model | | EA-121730+6 | | | |
|
|---|---|---|---|---|---|---|
| frequency range [MHz] | 6m | - | 50 - 52 | - | - | - |
| 10m | 28.0 - 29.7 | - | 28.0 - 29.7 | 28.0 - 29.7 | - | |
| 12m | - | 24.8 - 25.0 | - | - | - | |
| 15m | 21.0-21.45 | - | 21.0-21.45 | 21.0-21.45 | - | |
| 17m | - | 18.0-18.2 | - | - | - | |
| 20m | 14.0-14.35 | - | 14.0-14.35 | 14.0-14.35 | - | |
| 30m | - | 10.1-10.15 | - | - | - | |
| 40m | - | - | 7.0-7.3 | 7.0-7.3 | 7.0-7.3 | |
| 80m | - | - | - | 3.5 - 3.8 | 3.5 - 3.6 | |
| gain [dbi] | 6m | - | 3,0 | - | - | - |
| 10m | 3,0 | - | 3,0 | 3,0 | - | |
| 12m | - | 3,0 | - | - | - | |
| 15m | 3,0 | - | 3,0 | 3,0 | - | |
| 17m | - | 3,0 | - | - | - | |
| 20m | 3,0 | - | 3,0 | 3.0 | - | |
| 30m | - | 3.0 | - | - | - | |
| 40m | - | - | 2.0 | 2.0 | - | |
| 80m | - | - | - | 1.2 | - | |
| ENROYCE (OHM) | 50 | |||||
| Max. Potenza (Watt) | 1500 | |||||
| Max. Length (m) | 10.5 | 13.20 | 13.00 | 27.00 | 27.00 | |
| weight (kg) | 0.9 | 1.5 | 1.34 | 2,8 | 2,0 | |
17910.372H
Data sheet
- MPN
- 7438641839230
- Sku
- 17910.372H
