The Amplifier of Postena ACOM 1000 has a backlit LCD display exhibition text messages, one of the 12 parameters and a bar graph for the peak output power. Additional LEDs indicate various operating states such as "operated", attenuator and on / off the ACOM-1000 is completely compatible with BK (QSK), it provides a power of 1000 W on all radioaamatory bands from 160 to 6 m. {
{
technical characteristics
- frequency coverage: all amateur bands in range 1.8-54.7 MHz, extensions or variations on request. {
- {
- Output power: 1000 W PEP or with continuous carrier, no operating way limit. {
- intermodulation products: better than -35db than the nominal output level. {
- {
- A bucket to the network and noise frequency: better than -40db than the nominal output level. {
- {
- Harmonic suppression Outgoing:
- {
- 1.8-29.7mHz - better than 50db than the nominal output level; {
- {
- 50-54MHz - better than 66db than the nominal output level. {
- {
- Entry and output impedance:
- {
- nominal value: 50 Ω unbalanced, UHF type connector (SO239)
- {
- input circuit: large gang, VSWR less than 1.3: 1, on the entire 1.8-54MHz range (it does not require harmony nor commutations)
- {
- bypass path with VSWR less than 1.1: 1, on the entire range 1.8-54MHz
- {
- EVENT REQUEST OUPPLER EVENT (ANTENNA): with VSWR up to 3: 1 or more with reduced power levels. {
- {
- RF gain: 12.5 DB typical, frequency response with a variation of less than 1DB (from 50 to 60 W of piloting power for the nominal output power). {
- {
- power network requirements: 170-264 V ac (200, 210, 220, 230 & amp; 240 vnominal, took for 100.110 & amp; 120v on request), +10% -15% of the.), 50-60 Hz, single-phase, 2000 va. {
- {
- in accordance with EC safety requirements and electromagnetic compatibility as well as to FCC regulations (band of 6, 10 & amp; 12 m blocked). {
- Dimensions and weight: LXPXA: 422x355x182mm, 18kg. {
- {
- Operating environmental conditions:
- {
- Operating temperature: 0 ...+50 degrees Celsius; {
- {
- humidity: up to 75% @ +35 degrees Celsius. {
- {
- Altitude:Up to 3000m at sea level without downgrading or reduction of the output power.
