ICOM IC AD R8600 scanner receiver from 10khz to 3 GHz

with the possibility of decoding digital communications

The IC-R8600 is able to decode digital signals with different protocols included

P25 (phase 1), NXDN ™, DPMR ™, D-Star, the Japanese protocol DCR (Digital Convenience Radio).  {

The reception of conventional analog signals includes all the modalities:

{ USB, LSB, FSK, CW, AM, S-AM (AM-Sningrona), FM and WFM, with a 10 kHz coverage to 3 GHz with 1 Hz. {{}

In the RSSI power indicator the values ​​measured in S-Meter, DBµ, DB (EMF) and DBM are displayed. The measurement in DBµ, DBµ (EMF) and DBM reaches a precision of ± 3 db * (between 0.5 and 1100 MHz). {

{ * less than ± 6 db between 1100 and 3000 MHz.

The IC-R8600 uses FPGA and DSP unit for demoding, the decoding of most signals. Direct HF signals and intermediate frequency signals, which are converted by the VHF/UHF signals are digitized in a 14 -bit A/D converter and sent to the FPGA and DSP units for optimal processing. The frequency sampling at 122.88mHz used for the A/D converter allows a significant reduction in image reception. {

The IC-R8600 is equipped with 11 different RF Passabanda filters for HF bands and 13 Passabanda filters in the VHF/UHF bands. To prevent an overload of the receiver (overflow) only the selected signal passes while the strong interference out of the range are rejected. The IC-R8600 reaches +30 IP3 DBM and 105 dB of dynamic range at 14.1 MHz. IP3 is +10 dBM at 144 MHz and 0 dBM at 440 mHz.

up to 2000 ordinary memory channels assigned to 100 groups. In addition, up to 100 scanning channels and 50 couples of frequencies for the scan limits. The automatic storage function records frequencies with activities in dedicated channels (up to 200). These memory channels and the different settings can be modified by Windows® PC with the optional CS-R8600 software.

a wide variety of research functions of the desired stations. The IC-R8600 is able to scan up to 100 channels per second in the Memorie Scan mode.

the high-resolution in real time spectrum analyzer provides high-level performance such as the high resolution, the speed of SWEP up to SWEEP up to 30 frames per second*, a range of range of 2.5 MHz and 110 dB of the dynamic range (at ± 2.5 kHz of Span). The cascade display (Waterfall) allows you to identify weak signals by showing the change of spectrum on a temporal scale. By touching on the screen the part of the spectrum analyzed can be set as an operational frequency. The peak search function finds the various frequency peaks inside the range and helps to select them.

* Approximate Value Span>

to acquire signals efficiently, The IC-R8600 user interface allows you to operate quickly and accurately. The large 4.3 ″ color display with touch screen functions is configured to collect all operational information. {

touching indications and icons on the screen, the management menu will appear and all the parameters can be easily regulated. {

{ Through the pressure of one of the multifunction control knobs A, B or C, you can view the menu through which to adjust various functions such as the scan speed, the RF gain, the audio shades, the backlight of the screen and other types of menu. {

The recording function allows you to store the audio received on an SD card in the wave format. The registered item can be listened to by the receiver or on a PC. If you use a 32 GB SD card you can save up to 270 hours of audio recording. In addition, it is possible to "photograph" a screen image and save it in PNG or BMP format on the SD card. {

*The SD card is to be purchased separately. {

{ The optional RS-R8600 software allows you to listen to the audio received and control most of the receiver functions, including the spectrum meter, through an IP network or a USB cable. {
