ACOM 1200S 50 MHz 1200 Watt-0 linear amplifier

ACOM 1200S 50 MHz 1200 Watt-1 linear amplifier

ACOM 1200S 50 MHz 1200 Watt linear amplifier

Name: ACOM 1200S 50 MHz 1200 Watt linear amplifier
Brand: ACOM
SKU: acom 1200s
Price: 3299 EUR
Availability: InStock

{

Delivery times from 1 to 2 weeks

{

Mách shop cách áp dụng Freeship không lỗ mà tăng lợi nhuận – GHN.VN Giao Hàng Nhanh

{

Immagini di Marchio Garanzia 2 Anni - Download gratuiti su Freepik

Reference acom 1200s

In Stock

€3,299.00

Order processing times and shipping times:

Order processing includes: order registration after payment, adding the order to the list of previously registered orders, replenishing the product if it is not in stock, checking the product, packaging the product, preparing a shipping label for the product, and handing over the shipment to the courier.

Orders are generally processed within 3 business days of receiving payment, however, we strive to fulfill orders the same day whenever possible.

Once the goods have been picked up by the courier, it is not possible to change the shipping address or cancel the order.

When will it arrive?

Shipping and delivery times for products entrusted to the courier vary from 1 to 5 business days.

Deliveries are made Monday through Friday.

Delivery times are purely indicative and are in no way binding. Shipments are handled by external couriers (e.g., Poste Italiane Group, SDA, GLS, BRT, UPS, DHL, MailBoxes, etc.), so we cannot guarantee a specific delivery date, only an approximate timeframe.

Deliveries are subject to undetermined variations during holidays, unexpected or planned carrier strikes, shipment management issues with the courier, or significant weather conditions.

Deliveries may be delayed if the shipping company encounters management issues: e.g., misdirected shipments to other regions, lost shipments, adverse weather conditions, locations not served daily, delays during the Christmas period, delays during the Black Friday period, etc.

{

The ACOM 1200 S SOLID State amplifiers + 6 meters cover amateur bands from 1.8 to 54 MHz. {{{} provide a exit power of 1000 W (PEP or continuous carrier) with less than 50 W of drive. { their operating parameters are displayed on a high resolution multifunction display. {

{

High resolution color display with five inches (5 inches) (108 x 65 mm), 800 x 480 pixels and 24 -bit color, t ransistor with field effect (mosfet) of the Blf188 type of NXP, designed to resist a high disdaining (SWR). {

{

{ technical characteristics
a) nominal power: 1000w +/- 0.5 db PEP or continuous carrier (1200w max)
b) distortion for intermodulation (IMD3): better than 30 db under the nominal power under the nominal power Pep
C) Suppression of harmonics and spuries: better than 60 dB (generally 65 dB); {
D) entrance and output impedance: nominal value 50 ohm unbalanced, UHF connectors (SO239); {
e) entrance circuit: large band, SwR below 1.2: 1 (generally 1.1: 1); {
F) frequency coverage: from 1.8 to 54MHz in continuous harmony without the need for rising; {
g) output circuit: by-pass with non-operational amplifier with SWR below 1.1: 1 from 1.8 to 54MHz; Maximum SWR ratio that can be bearable greater than 3: 1 with proportional power reduction - up to 1.5: 1 the amplifier will provide maximum output power; {
H) RF power gain: 13 db +/- 1 dB; {
i) Network voltage: 93 - 265v without the need for switching; {
l) Energy consumption of energy at full power: 2000va or not, with power factor equal to 0.95 or higher; {
m) Energy consumption in stand-by mode: less than 1va;
n) compliant with European safety standards and electromagnetic compatibility standards, as well as to the rules established by the Federal Communications Commission US (FCC);
o) environment and working conditions: temperature from -10 ° C to +40 ° C (14 ° F -104 ° F); Relative humidity up to 95%;
p) Dimensions and weight (PXLXA): 418x372x162mm (16,46x14,65x6,38in) - 12kg.

supplied with:
-a power cord
-a manual with a declaration of conformity ce Style = "Margin: 0px; Padding: 0px; Border: 0px; Vertical-Align: Inherit; Background-Size: Initial; Font-Family: Arial, Sans-Serif;">-Four spare fuses: 2x6.3a / 250V for operation with Network 200-240Vac and 2x10A / 250V for operation with network operation 100-120vac.
